A traditional-looking multi-standard CB transceiver covering the UK40 and EU CB bands, supplied ready to fit in a car or van. - Frequency range: 25.615-28.305 MHz - 80 channels, AM/FM, PLL frequency control - Maximum RF power: 4W at 13.8V DC - DC input voltage: 13.8V DC 15% - Antenna impedance: 50 ohm unbalanced - Receiver: CPU-controlled double-conversion superheterodyne - Intermediate frequency: 10.7 MHz / 450 kHz - Sensitivity: -120 dBm for 12 dB SINAD (FM), -107 dBm for 12 dB SINAD (AM) - Audio output: 2.5W at 8 ohm (10% THD) - Image rejection: 65 dB; adjacent channel: 85 dB; signal-to-noise ratio: 45 dB - Operating temperature: -10 C to +55 C - Dimensions: 38 mm (H) x 115 mm (W) x 150 mm (D); weight 0.8 kg - Front-panel RF gain and squelch controls with quick-access channel 9/19 knob - Supplied with command microphone (up/down channel selection), DC lead with cigarette plug, mounting trunnion bracket with thumb screws and microphone hanging bracket
A high quality CB rig covering the UK40 and EU CB frequencies. The 8000l. whilst traditional in appearance. has a wealth of modern features typically only found in more expensive rigs. Included with the radio is DC lead with fitted cigarette plug. perfect for connecting straight to the car or van. as well as a command microphone featuring Up and Down channel selection buttons. The radio features RF gain and squelch controls. as well as a quick access channel 9/19 knob. Also supplied with the kit is a mounting trunion bracket. with thumb screws. as well as a microphone hanging bracket. Key Features/Specifications: Frequency Range : 25.615 - 28.305 MHz Channels 80 AM/FM Frequency control P.L.L. Operating temperature -10°/+55°C DC input voltage 13.8Vdc ±15% Size 38mm (h) x 115mm (W) x 150mm (D) Weight 0.8 kg Transmitter System CPU controlled P.L.L. synthesizer Maximum RF power 4W at 13.8Vdc Modulation 85% to 90% (AM) 1.8 KHz ±0.2 KHz (FM) ANT impedance 50 ohm unbalanced Current drain 1000mA (at no modulation) Receiver System CPU controlled Double conversion super IF 1° 10.7 MHz / 2° 450 KHz Sensitivity -120dBm for 12dB SINAD (FM) -107dBm for 12dB SINAD (AM) Audio output @10% THD 2.5W at 8 ohm Audio distortion <8% at 1 KHz Image rejection 65dB Adjacent channel 85dB Signal ise ratio 45dB Current drain 220mA (stand-by)
| Title | PNI HP8000L AM/FM CB Radio Transceiver (12V) |
|---|---|
| Brand | PNI |
| Category | CB Radios |
| SKU | OaFPTbZ |
| Condition | new |
| Weight | 1.0 kg |
